SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
12 / 20 artikelnr. 28 100 59 e
Stap
Ingeeffunctie
Ingegeven
waarde
deaktiv
activeren met [+] / [-] open
aktiv met Enter bevestigen
Ein 10% AAN: instellen met [+] / [-] [Enter]
Aus 12% UIT: instellen met [+] / [-] [Enter]
Ein +0°C AAN: instellen met [+] / [-] [Enter]
Aus +0°C UIT: instellen met [+] / [-] [Enter]
Relais buiten werking door deactive of ingeven
van 0% of 0°C (steeds bij On en Off)
Aan ______%
Uit ______%
Aan ______°C
Uit _______°C
7.Relais 2
SmartBox2
o. 7.Relais
SmartBox 3
Ingave voor Relais 2 zie 7. Relay1
Aan ______%
Uit ______%
Aan ______°C
Uit _______°C
8.Exit/
Sortie
[Enter] voert terug naar de indicatiemodus
Nadat de ingegeven stappen 1 - 7 zijn ingesteld is het programmeren beëindigd. Het
apparaat gaat met de bevestiging van stap “8 Exit” automatisch naar de indicatiemodus en
in het display verschijnt de actuele tankinhoud.
Onder de stappen 9 tot 24 staan speciale functies ter beschikking (zie bladzijde 10).
Het deksel van de behuizing er weer opschroeven nadat de inbedrijfstelling is afgesloten!
Na afsluiting van de MONTAGE en de PROGRAMMERING wordt geadviseerd een functietest
uit te voeren (hoofdstuk: FUNCTIETEST).
VOORBEELDEN VOOR HET PROGRAMMEREN
Voorbeeld 1: Keldertank voor 6000 l stookolie, indicatie in liters, lineaire stalen tank
binnenwerkse hoogte165 cm, (vulstand 125 cm)
SmartBox
®
1 met Standaard peilsonde 0 - 250 mbar
Stap
Ingeven / Keuze
1. Sonde
250 mbar
2. Medium stookolie
Heat oil
3. Tankvorm lineair
Linear
4. Volume van de tank 6.000 liter
6000 L (met [+]/[-] instellen)
5. Binnenwerkse hoogte tank 165 cm
165.0cm (met [+]/[-] instellen)
5b.Vulgrens
95%=157cm (met [+]/[-] instellen)
6.Weergave
Weergavede-tails
Vulruimte+procent
(indicatie 2e lijn - (met [+]/[-] instellen)
7. Exit
met ENTER geeft indicatie
Heat oil 4.550L
-1.150L 76%
