GOK SmartBox 1 Assembly And Operating Manual

SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
part no. 28 100 57 f 15 / 20
Menu
Setting
Description
13.Rounding
Automatically
Without rounding
20L
50L
100L
200L
500L
1.000L
Default settings
minimal increments
Rounding increments in relation to the set volume
set with [+] / [-] keys
14.–17.Exit
Press [Enter] to return to display mode
18.Language
+ name
Language:
German, English, French [+] / [-] / [Enter]
Name:
ESC [+] / [-] / [Enter]
Name Tank 1: Suggested name
 Letters can be changed with [+] / [-] / [Enter]
19.Exit
Press [Enter] to return to display mode
20.LCD
display
Contrast: 24
Set the contrast of the LCD display
21.Device
info
Software version: V6.00 (e. g.)
Serial number: Tank 1: SN=1234 (e. g.)
Offset + Gain: X0 = 4.05mA; B = 1268
22.Test
current
Test function for the current mA value of the
probe: ADC = 7400 = 11.40mA
If level probe is not submerged, the value should
be close to 4mA. Tolerance range is 3.7..4.3mA.
Furthermore, devices connected on the relay contact will also be switched
on and/or off!
• Connected devices can be damaged (dry running).
• Operating media may leak.
Disconnect the devices connected before test relay.
Only reconnect the devices again after test relay.
23.Test
relay
 SmartBox
2 und 3
Relay 1 or
Beeper =Off/On
Relay 2=Off/On
Test function for the switch function of relay and
beeper
24.Reset
ESC
Exit this function without executing it.
Restart
Initialisation. The device software restarts and
keeps all device settings.
Factory settings
Complete reset of all parameters to the original
delivery status.
26.Exit
Press [Enter] to return to display mode
