Goodwe EM Series User Manual

01 INTRODUCTION
TABLE OF CONTENTS
1.1 Operation Modes Introduction
1.2 Safety & Warnings
1.3 Product Overview
....................................................................................... 01
.............................................................................................................. 02
............................................................................................................. 04
03 MANUAL OPERATION
3.1 Wi-Fi Configuration
3.2 PV Master App
3.3 CEI Auto-Test Function
.......................................................................................................... 21
................................................................................................................... 22
.................................................................................................... 22
04 OTHERS
4.1 Error Messages
4.2 Troubleshooting
4.3 Disclaimer
4.4 Technical Parameters
4.5 Other Tests
4.6 Quick Safety Check List
.................................................................................................................. 23
................................................................................................................ 25
.......................................................................................................................... 30
...................................................................................................... 31
.......................................................................................................................... 33
.................................................................................................... 33
2.1 Incorrect Installation
2.2 Packing List
2.3 Mounting
2.3.1 Selecting a Mounting Location
2.3.2 Mounting
2.4 Electrical Wiring Connection
2.4.1 PV Wiring Connection
2.4.2 Battery Wiring Connection
2.4.3 On-Grid & Back-Up Connection
2.4.4 Smart Meter & CT Connection
2.5 DRED and Remote Shutdown Device Connection
2.6 Earth Fault Alarm Connection
2.7 SEMS Portal
......................................................................................................... 05
....................................................................................................................... 05
........................................................................................................................... 06
.............................................................................. 06
.................................................................................................................. 07
........................................................................................... 09
............................................................................................ 09
.................................................................................... 10
............................................................................ 11
.............................................................................. 15
....................................................... 17
......................................................................................... 18
......................................................................................................................... 18
02 INSTALLATION INSTRUCTIONS

Goodwe EM Series Specifications

General

Type	Hybrid Inverter
Battery Voltage Range	40V to 60V
Max PV Input Voltage	500V
Number of MPPTs	2
Protection Rating	IP65
Communication	WiFi, RS485, USB
Rated Power Output	3000W, 3600W, 4200W, 5000W
Max Charging Power	3kW
Max Discharging Power	3kW
Nominal AC Output Power	3kW to 6kW
Max PV Input Power	4500W, 5400W, 6300W, 7500W
Max AC Output Power	3kW to 6kW
AC Output Voltage	230V
AC Output Frequency	50/60Hz
Operating Temperature	-25~60 °C
Cooling Method	Natural Cooling
Model	EM Series
