37
B Display area
The display area is divided into top, middle and bottom areas.
TOP AREA
` The top area displays the status information.
“Waiting” indicates the inverter is standby for power
generation;
“Checking 30S” indicates the inverter is self-checking,
counting down and preparing for power generation
(checking time is based on safety, and varies from country
to country);
“Normal” indicates the inverter is generating power.
If any condition of the system is abnormal, the screen will
display an error message; please then refer to Table 4.4-1.
` By pressing the key successively, the display in this top area
of the screen will scroll through different information, such
as operation parameters and power generation status. More
guidance on navigating through the menus is given in C to
H below.
MIDDLE AREA, LEFT
` The electrical connections on the DC side and the AC side
are represented by dashed and full lines.
` A flashing dashed line on the DC side indicates the PV
panel is feeding power to the inverter.
` Nothing showing on the AC side means the grid is not available;
