38
` A full line on the AC side means the grid is available, but
the inverter is not generating power ;
` A flashing dashed line on the AC side indicates the inverter
is feeding power to the grid network.
MIDDLE AREA, RIGHT
` In this area, a histogram is used to represent the hourly
average power generation from 4 a.m. to 8 p.m. on the
current day. A full column for average power represents the
nominal power of system.
BOTTOM AREA
The bottom area displays total power generation, daily power
generation, power being generated at present, and time
information, as described below:
Part Description
E-TOTAL Gross power generated from the first use of the inverter. The
initial unit is “kWh”; when power generation exceeds
9999.9kWh, the unit changes to “MWh”.
E-DAY Power generated for the current day
POWER Present power generation of the system
TIME Current system time
C Key operation
There are 2 modes of key operation:
