Goodwe HT Series User Manual

15
User Manual V1.1-2022-07-20 05 Installation
1. The mounting support shall be nonammable and reproof.
2. Make sure that the support surface is solid enough to bear the product weight load.
Mounting Support Requirements
0%~100%RH
IP66
ALT: 5000m
Installation Angle Requirements
• Install the inverter vertically or at a maximum back tilt of 25 degrees.
• Do not install the inverter upside down, forward tilt, back forward tilt, or horizontally.

Goodwe HT Series Specifications

General

Max DC Input Voltage	1100V
MPPT Voltage Range	200-1000V
Max AC Output Power	3.6kW to 10kW
Number of MPPTs	1 or 2
Max PV Input Voltage	1100V
MPPT Range	200-1000V
AC Output Frequency	50/60Hz
Communication	RS485, Ethernet
Operating Temperature Range	-25°C to 60°C
Protection Level	IP65
