19
User Manual V1.1-2022-07-20 05 Installation
Hoisting the Inverter
M6
3~3.5N·m
3
2
1
1
2
M6
3~3.5N·m
3
The DC switch locking
hole is for Australia only.
The DC switch locking
hole is for Australia only.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Goodwe HT Series and is the answer not in the manual?

Goodwe HT Series Specifications

General IconGeneral
Max DC Input Voltage1100V
MPPT Voltage Range200-1000V
Max AC Output Power3.6kW to 10kW
Number of MPPTs1 or 2
Max PV Input Voltage1100V
MPPT Range200-1000V
AC Output Frequency50/60Hz
CommunicationRS485, Ethernet
Operating Temperature Range-25°C to 60°C
Protection LevelIP65
