06 Electrical Connection
User Manual V1.3-2023-01-31
26
Power limit networking scenario (single inverter)
PE
RS485+
RS485-
L1
L2
L3
N
CT
CT
CT
Smart meter
Grid
Meter
Inverter
Three-phase
circuit breaker
RS485+
Ethernet
RS485-
L1
L2
L3
N
PE
CT
CT
CT
......
Power limit networking scenario (multi inverters)
Three-phase
circuit breaker
Inverter 1
Router
Meter
Cloud
Grid
Inverter N
After completing cable connections, set related parameters via LCD or SolarGo app to enable
export power limit control or output power limit control.
SEC1000
Inverter
EzLogger Pro
Internet
Router
PC
RS485 RS485 RS485
LAN
Inverter
Inverter
...
RS485 networking scenario
