Goodwe SMT Series User Manual

User Manual V1.3-2023-01-31 06 Electrical Connection
27
Connecting DRED or RS485 6pin Communication Cable (optional)
Contat the after-sales service to get the DRED terminal if you need to use DRED function.
DRED function is o by default. Start this function via SolarGo App if it's needed.
DRED: For Australia only.
2
2
4
1
3
M2
0.3~0.4N·m
1
2
1
3
4
5
6
7
1
2
2
1
2
3
4
5
6
1
3
2
4
5
NO. RS485
1 RS485-A1
2 RS485-B1
3 RS485-A1
4 RS485-B1
5 RS485-A2
6 RS485-B2
NO. DRED
1 DRED1
2 DRED2
3 DRED3
4 DRED4
5 REF1
6 REF2
DRED
RS485
6.5mm
25mm
