Gooxi G2SERO-B User Manual

Version: V1.1 69
Chapter 4 RAID Setting Instruction
4.1 LSI 9361-8i builds RAID
4.1.1 Configuring RAID in UEFI boot mode
 Enter RAID card configuration interface
a) During the server startup, press Delete/ESC according to the prompt to enter the BIOS Setup
interface.
b) Select Advanced>AVAGO MegaRAID<AVAGO MegaRAID SAS 91311-8i>Configuration Utility,
press Enter.
c) Enter the interface shown in Figure 4-1, where five types of configuration tasks are displayed (see
Table for related instructions).
Figure 4- 1
 Table of Parameter description
Parameter
Description
Configuration Management
Select configuration management to perform tasks such as creating logical disks, viewing
disk group properties, viewing hot backup information, and clearing configuration.
Controller Management
Select controller management to view and manage controller properties and perform tasks
such as clearing controller events, scheduling and running controller events, and running
patrol read.
Virtual Drive Management
Select logical disk management to perform tasks such as viewing logical disk properties,
locating logical disks, and running consistency checks.
Drive Management
Select disk management to view the physical disk properties and perform tasks such as
locating the disk, initializing the disk, and rebuilding the disk after failure.
Hardware Components
Select hardware components to view supercapacitor properties, manage supercapacitors
and peripheral components.
