Gooxi SR201 2U User Manual

19
3 PCIe X8 slots
Full
height,
full length
Riser 3
CPU 1
PCIe x
16 (3.0/4.0)
1 PCIe X16 slot
Half
height,
half
length
CPU 1
2 PCIe X8 slots
Half
height,
half
length
Riser 4
CPU 1
2*Silmline
X8
1 PCIe X16 slot
Half
height,
half
length
CPU 1
2 PCIe X8 slots
Half
height,
half
length
Notice:
◆ The slot with bus bandwidth of PCIe x16 is backward compatible with PCIe cards of
PCIe x8, PCIe x4 and PCIe x1. Up is incompatible, that is, the bandwidth of the PCIe slot
cannot be smaller than the bandwidth of the inserted PCIe card.
◆ Full-height and full-length PCIe slots are backward compatible with full-height and
half-length and half-height and half-length PCIe cards; slots with full-height and
half-length PCIe slots are backward compatible with half-height and half-length PCIe
cards.
◆ The power supply capacity of all slots can support a PCIe card with a maximum of 75W,
and the power of the PCIe card depends on the model of the PCIe card.
Table (2-12)
2.8. 3 PCIe expansion module
 PCIe expansion module 1
Riser card for x24 to x16+x8
– Installed at the Riser1 position, providing 1 PCIe X16 slot and 2 PCIe X8
slots;
– Installed at Riser2, providing 1 PCIe X16 slot and 2 PCIe X8 slots;
Figure (2-18)
 PCIe expansion module 2
Riser card for x24 to x8+x8+x8
– Installed at the Riser1 position, providing three PCIe X8 slots for PCIe
slots;
– Installed at the Riser2 position, providing three PCIe X8 slots for PCIe
