Gorilla Playsets Chateau - Page 17

5/16" TEE NUT
QTY: 38
#8 X 2-1/2"
WOOD SCREW
QTY: 48
#8 X 3"
WOOD SCREW
QTY: 8
3
2
5
6
7
8
9
1
4
USE THE RULER TO THE RIGHT TO MEASURE YOUR BOLTS AND SCREWS. PICTURE VIEWS SHOWN
ABOVE ARE 1:1 SCALE AND CAN BE USED TO MATCH BOLT AND SCREW SIZES.
#8 X 2"
WOOD SCREW
QTY: 227
#8 X 1-1/2"
WOOD SCREW
QTY: 140
#14 X 1-1/4"
PAN HEAD SCREW
QTY: 4
1/2" WASHER
QTY: 2
TORQUE WASHER
QTY: 17
3/8" WASHER
QTY: 31
3/8" LOCK NUT
QTY: 19
5/16" WASHER
QTY: 58
5/16 X 4-1/2"
HEX BOLT
QTY: 30
5/16 X 1-1/2"
HEX BOLT
QTY: 8
