Gorilla Treasure Trove II User Manual

#8 X 2" WOOD SCREW
A
STEP 32: UPPER LEVEL DECK BOARDS
SCREWS.
2: SECURE EACH UPPER DECK BOARD TO THE DECK SUPPORTS WITH FIVE #8 X 2" WOOD
DECK SPACER.
SHOWN. EQUALLY SPACE THE DECK BOARDS 5/16" FROM ONE ANOTHER AND FROM THE
1: PLACE FOUR 5/4 X 6 X 69-7/8" UPPER DECK BOARDS ACROSS THE DECK SUPPORTS AS
5/4 X 6 X 69-7/8"
DECK BOARD
DECK SPACER
SCALE 1 : 12
DETAIL A
5/16" GAPS
DECK BOARD
77
