STEP 33: SLIDE POST ASSEMBLY
1: PREDRILL TWO 1/8" PILOT HOLES CENTERED VERTICALLY ON THE NOTCH IN THE
4 X 4 X 43-1/2" RAD RIDE CENTER POST.
2: PLACE ONE END OF THE 5/4 X 4 X 25" RAD RIDE DECK SPACER INTO THE NOTCH IN THE
RAD RIDE CENTER POST. THE END WITHOUT ANY PREDRILLED HOLES GOES INTO THE
NOTCH.
3: FASTEN THE RAD RIDE DECK SPACER TO THE RAD RIDE CENTER POST WITH TWO #8 X 3-
1/2" WOOD SCREWS.
PILOT HOLES
#8 X 3-1/2" WOOD SCREWS
CENTERED VERTICALLY
PREDRILL TWO 1/8"
5/4 X 4 X 25" RADRIDE DECK SPACER
NOTCH
ON THE NOTCH.
4 X 4 X 43-1/2" RAD RIDE CENTER POST
WHEN YOU
RECEIVE THIS
BOARD IT WILL
HAVE TWO HOLES
PREDRILLED IN THIS
END.
