Grace Cutie - Page 30

30
Cutie Frame
Place each hoop side rail into a top rail corner so the end with the hole rests in the corner.
12
Hoop Side Rail
(x2)
Place the front rail onto the two top rail corners so the keyhole cutout faces away from
the corners, and the long front rail is to the left.
11
Top Rail
Corner (x2)
Keyhole
Cutout
Long Front Rail
Task 8 - Installing the Rails (Continued)
With the 2 mm Allen wrench, tighten the pre-installed set screws in the front rail.
10
