Technical Data
Model, C02078
Category Data
Maximum fluid working pressure All other metering valves: 3200 psi (22.0 MPa, 220 bar)
Minimum fluid working pressure 50 psi (0.34 MPa, 3.4 bar)
Minimum air supply pressure 80 psi (0.55 MPa, 5.5 bar)
Viscosity range 3000 to 1 million centipoise
Shot size range 0.2 to 4.0 cc
Shot cycle rate 15 shots per minute, at 4.0 cc shot size with moderate viscosity
fluid
Fluid inlet 1/4 npt(f)
Air supply inlet 1/8 npt(f)
Fluid outlet 1/4 npt(f)
Mounting hole 7/16–20 unf–2B
Piston Air-operated, spring return
Wetted parts Viton o-rings
Weight 1.43 lb (.65 kg)
Viton
