Parts
12 306436M
Ref 3, Part 204867, Series A
Hand Pump Assembly
Reference Parts, page 6.
* Keep a spare on hand to reduce down time.
Ref. Part Description Qty.
301 200753
PISTON ASSEMBLY, includes
items 301a - 301f
1
301a 100114 BALL, steel, 7/16 in. dia. 1
301b 150134 SPRING, compression 1
301c 150463 GLAND, male 1
301d* 151464 V-PACKING, leather 3
301e 150465 SEAT, piston 1
301f 152559 HOUSING, piston 1
302 202162
INTAKE VALVE HOUSING,
includes items 302a - 302d
1
302a 101021 RING, retaining 1
302b 156738 VALVE, poppet 1
302c 156739 BODY, valve 1
302d 156750 GUIDE, poppet 1
303 100133 LOCKWASHER, spring, 3/8 in. 1
304 100184 CAPSCREW, hex, 5/16-24 x 1 in. 1
305 100187 NUT, hex, 5/16-24 1
306 100191 NUT, wing, 5/16-18 1
307 100214 LOCKWASHER, spring, 5/16 in. 1
308 100340 NUT, hex, 3/8-16 1
309 101120 SCREW, rd hd, 1/4-20 x 1-1/4 in. 4
310 150662 SCREW, pivot 1
311 150726 CLEVIS 1
312 154513 PACKING NUT 1
313* 154514 PACKING, duck and neoprene 2
314 156511 RISER TUBE 1
315 156593 O-RING, nitrile rubber 1
316 158769 LEVER, pump handle 1
317 159487 SPACER 1
318 159488 TUBE, extension 1
319 159923 HOUSING, outlet 1
320 159930 CONNECTING ROD 1
321 159931 SCREW, pivot 1
322 100119 ELBOW, 1/2 npt 1
