Setup
16 3A3489T
Pressurize the Pot
1. Verify that the pot seal plunger (E) is in the down
position and the top of the plunger is clean of
abrasive media.
2. Verify that the rinse valve (U), abrasive ball valve,
(J), the pot dump valve (F), and the quick drain
valve (ZH) are closed.
3. Verify that the water level in the pot (C) is above the
pot seal plunger (E).
4. Disengage the emergency stop (L).
NOTE: The water pump will not work unless the
Emergency Stop is disengaged.
5. Turn the selector valve (T) to BLAST
6. Pull upwards on the pot seal plunger (E). Hold until
the pot pressure on the pot pressure gauge (H)
rises to 185 psi.The pressure holds the pot seal
plunger in place.
To avoid injury to the operator, always pressurize the
pot before opening the abrasive ball valve (J) or
engaging the blast control switch (A).
WLE
8
8
0
0
0
0
0
0
WLLD
/
WLD
ti39819a
E
H
