Technical Specifications
3A3489T 51
Technical Specifications
EQm
California Proposition 65
EcoQuip 2 EQm
US Metric
Maximum Inlet Air Pressure 175 psi 10.3 bar, 1.03 MPa
Maximum Inlet Water Pressure 100 psi 6.9 bar, 0.69 MPa
Operating Temperature 35°–110° F 1.6°–43.3° C
Recommended Compressor Size+ 185–600 CFM 5.3–17 m3/min
Blast Hose Size (supplied)
1.25 in. ID
31.75 mm ID
Abrasive Capacity* 440 lb 200 kg
Dry Weight 370 lb 168 kg
Wet Weight* 900 lb 408 kg
Pressure Pot Volume 3.5 cubic feet 99 liters
Air Inlet Connection† 1-1/2 npt
Water Inlet Connection
3/4 in. garden hose
connection
19 mm garden hose
connection
*Abrasive capacity and wet weight was found using 80 grit garnet. Using coarser media or less dense media
will decrease weight.
† 2 in. ground boss adapter included in tool box (see Parts section of the EcoQuip 2 manual for more detail).
Air Supply Hose Minimum ID
185–600 CFM compressor and less than 100 ft
hose length
1.5 in. ID 38 mm ID
Over 600 CFM compressor or greater than 100
ft hose length
2 in. ID 51 mm ID
Sound Data**
Sound Pressure Level 133 dB(A) 133 dB(A)
Sound Power Level 139 dB(A) 139 dB(A)
Instantaneous Sound Pressure Level 131 dB(C) 131 dB(C)
**All readings were taken at the maximum system blast pressure 150 psi (10.3 bar, 1.03 MPa) from the
operator position. The abrasive used was garnet and the substrate was steel. Tested in accordance with ISO
9614-2.
+ See the Nozzle Selection Guide for information on how to properly select the blast nozzle based on
compressor pressure and flow output specifications.
Notes
All trademarks or registered trademarks are the property of their respective owners.
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
