Repair
3A3489T 33
Repair
Replace the DataTrak Battery
Replace Battery
1. Unscrew cable from the back of the reed switch
assembly.
2. Remove the cable from the two cable clips.
3. Remove the DataTrak module from the bracket.
Take the module and attached cable to a
non-hazardous location.
4. Remove the two screws on the back of the module
to access the battery.
5. Disconnect the used battery and replace it with an
approved battery.
To reduce the risk of fire and explosion, the battery
must be replaced in a non-hazardous location.
Use only an approved replacement battery (see
table). Use of an unapproved battery will void
Graco's warranty.
WLE
Approved Batteries
Energizer
®
brand alkaline #522
Varta
®
brand alkaline #4922
UltraLife
®
brand lithium #U9VL
Duracell
®
brand alkaline #MN1604
WLE
