Graco EcoQuip 2 EQm Instruction Manual

Troubleshooting
30 3A3489T
While in BLAST
mode, with the blast
control switch (A)
engaged, air is flowing
from the nozzle but
little or no abrasive is
flowing from the
nozzle.
The abrasive ball valve
is closed.
See Setup, page 14.
The abrasive metering
valve is not properly
set.
See Setup, page 14.
The pot does not have
a sufficient amount of
abrasive.
See Standby, page 24.
The pinch valve does
not open.
Engage the blast control switch (A) and check for actuation of the
pinch valve. If there is no actuation, disconnect the orange tubing
at the pinch valve. If the pinch valve opens and source air is
coming from the orange tubing, confirm that the tubing is correctly
routed. If the pinch valve does not open, replace it. If the pinch
valve opens and there is no source air coming from the tubing,
inspect the mufflers on the 4-way valve for debris. If debris is not
present, clean or replace the 4-way valve.
There is an obstruction
inside the pot or inside
the abrasive hose
between the pot and
the enclosure.
Follow Drain the Pot, page 25, followed by the Pressure Relief
Procedure, page 17. With the abrasive hose disconnected,
inspect the interior of the pinch hose for obstructions or debris and
replace if necessary (see Replace the Pinch Hose, page 35).
Remove the tri-clamp from the bottom of the pot. Inspect the
bottom of the pot and the abrasive hose for obstructions or debris.
The pot pressure is too
low.
With the blast control disengaged, allow the pot to pressurize and
wait for the pump to stall. If the pot pressure gauge does not reach
185 psi (12.75 bar, 1.275 MPa), see the “Unable to fill or
pressurize the pot with water” problem listed on this table.
The blast pressure is
too high.
If the blast pressure gauge reads 160 psi (11.03 bar, 1.10 MPa) or
greater, it may not be possible to achieve than 15 CPM on the
MediaTrak. This is more common with fine mesh abrasive usage.
Decrease the blast pressure to 100 psi (6.9 bar, 0.69 MPa) to see
if CPM can be increased.
Problem Cause Solution
