Graco EcoQuip 2 EQm - Page 37

Parts
3A3489T 37
1.
Apply thread sealant to all non-swivel pipe threads.
Apply anti-seize to threads.
Torque to 60 +/- 5 ft-lb (81.3 +/- 6.7 N•m) with pot
pressurized.
2
3
The hand-way gasket must be installed centered and flat on
the hand-way cover.
Apply anaerobic sealant to threads.
7
8
