Operation

3A4802D 11

4. Open the compressor air supply valve (150 psi, 10.3

Bar, 1.03 MPa) maximum.

NOTE: Make sure the air supply meets the appro-

priate air flow requirements (see Technical

Specifications, page 45).

5. Connect the blast hose, hose restraints, control

hoses, and coupler pins.

WLD

NOTICE

Do not use a wrench when installing the nozzle. Dam-

age to the seal could occur. To avoid seal damage,

always hand-tighten the nozzle.

WLD
