Component Identification
6 3A4802D
Component Identification
System Component Identification
System Component Identification Key
WLD
$
%
%
&
(
-
.
/
0
:
3
7
5
=&
9
<
4
=
=$
=-
=*
)
;$
;&
;'
;%
;(
=)
;)
=+
*
;*
Ref. Description
AFrame
B Blast Control Switch
B2 Blast Nozzle
C Blast Hose
EPot
F Pop-up Handle
G Siphon Hose
JPot Dump Valve
K Pressure Relief Valve
L Pot Pressure Gauge
M Abrasive Ball Valve
P Control Box
Q Air Supply Valve
R Blast Pressure Regulator
T Abrasive Metering Valve
V Blast Pressure Gauge
W Selector Valve
Y Air Supply Connection
Z Blast Hose Connection
ZA Pneumatic Control Connection
ZC Supply Pressure Gauge
ZF Abrasive Material
ZG Pot Outlet Manifold
ZH Ground Wire and clamp
ZJ Pop-up Seal
XA Water Inlet Pressure Regulator
XB Abrasive Hose
XC Pump Inlet Hose
XD Fill/Flush Valve
XE Quick Start Guide
XF Pot Funnel
XG Garden Hose Connection
XH Siphon Hose Clip
XJ Garden Hose to Gardena Adapter
