Tubing Schematic
42 3A4802D
Tubing Schematic Key
★ T16 not shown - routes from the Garden Hose Connection to the Fill/Flush Valve outside of the control box.
Ref. Tubing Style Cut Length Inches (cm)
T1 Natural - 1/4 in. OD 14 in. (35.5 cm)
T2 Green - 1/4 in. OD 17 in. (43.1 cm)
T3 Green - 1/4 in. OD 9 in. (22.8 cm)
T4 Green - 1/4 in. OD 13 in. (33 cm)
T5 Green - 1/4 in. OD 10 in. (25.4 cm)
T6 Red - 1/4 in. OD 8.5 in. (21.5 cm)
T7 Orange - 1/4 in. OD 15 in. (38 cm)
T8 Yellow - 1/4 in. OD 27 in. (68.5 cm)
T9 Natural - 1/4 in. OD 16 in. (40.6 cm)
T10 Natural - 1/4 in. OD 33.5 in. (85 cm)
T11 Red - 3/8 in. OD 13.5 in. (34.2 cm)
T12 Red - 1/4 in. OD 7 in. (17.7 cm)
T13 Green - 1/4 in. OD 9 in. (22.8 cm)
T14 Green - 1/4 in. OD 11.5 in. (29.2 cm)
T15 Blue - 1/4 in. OD 24 in. (60.9 cm)
T16★ Clear - 3/8 in. OD 16 in. (40.6 cm)
