Technical Specifications
3A4802D 45
Technical Specifications
EcoQuip 2 EQp
US Metric
Maximum Air Inlet Working Pressure 150 psi 10.3 bar, 1.03 MPa
Maximum Fluid Working Pressure 185 psi 12.7 bar, 1.27 MPa
Operating Temperature 35° - 110° F 1.6° - 43.3° C
Recommended Compressor Size 185 CFM 5.24 m^3/min
Abrasive Capacity*
220 lb
100 kg
Dry Weight 220 lb 100 kg
Wet Weight 500 lb 227 kg
Pressure Pot Volume 2 cubic feet 56 liters
Air Inlet Connection** 3/4 in. Universal
Crowsfoot/Chicago Fitting
3/4 in. Universal
Crowsfoot/Chicago Fitting
Blast Connection*** 2 Lug Claw Coupler 2 Lug Claw Coupler
Water Inlet Connection**** 3/4 in. Garden Hose Connection 3/4 in. Garden Hose Connection
*Abrasive capacity and wet weight using 80 grit garnet.
** A 3/4 in. male NPT connects to the universal claw out of the system.
*** A 1.25 in. NPSM connects to the 2 lug claw coupler out of the system.
**** Siphon kit is included, adapter kit or water tank kit are available as accessories.
Air Supply Hose Minimum ID
Less than 185 CFM compressor and 100 ft of hose 1 in. ID 25.4 mm ID
Greater than 185 CFM compressor or 100 ft of hose 1.5 in. ID 38 mm ID
Wetted Parts
Electroless Nickel, Nylon, Brass, Stainless Steel, Coated Carbon Steel, Nickel Plated Brass, Anodized Aluminum, UHM-
WPE, PTFE, Nitrile, Tungsten Carbide, Acetal, Fluoroelastomer, Polyethylene, Leather, Buna, NBR, SBR, PVC.
Sound Data
Sound pressure level 107.2 dB(A)
Sound power level 113.2 dB(A)
Recorded when blasting steel with 0 garnet at a maximum blast pressure with a
1 in. blast hose, #8 nozzle, and a 375 cfm compressor set at 150 (10.3 bar, 1.03 MPa).
