Graco G3 - Page 36

Parts
36 332291P
Installation and Repair Kits Reservoir Conversion Kits
Fuses
Kit No. Description
Manual
Number
571026 KIT, output union, 3 pump
3A0523
571063 KIT, output union, 2 pump
571028
KIT, return to reservoir NPT,
includes pressure relief valve
16C807
3A0525
571071
KIT, return to reservoir BSPP,
includes pressure relief valve
16C807
24M478
KIT, vent valve, 12 volt DC, NO,
NPT DEU
3A0526
24M479
KIT, vent valve, 24 volt DC, NO,
NPT DEU
24M480
KIT, vent valve, 115 VAC, NO, NPT,
DIN
24N182 KIT, vent valve, 230 VAC
571036 KIT, cover with “G” label NA
571041
KIT, pump element, includes Ref
17, 18, 33
3A0533
571042
KIT, repair, 2 liter reservoir,
includes Ref 13, 36, 40
3A0534
571069
KIT, repair, 2 liter reservoir, for
models with follower plate,
includes Ref 13, 36, 40
571044
KIT, replacement, paddle, 2 liter,
for models without follower plate,
includes Ref 13, 16, 35, 57
3A0535
571045
KIT, replacement, paddle, 2 liter,
for models with follower plate,
includes Ref 13, 16, 35,40a, 42, 57
571046
KIT, replacement, paddle, 4-16
liter, for models without follower
plate, includes Ref 13, 16, 35, 57
571047
KIT, replacement, paddle, 4 liter,
for models with follower plate,
includes Ref 13, 16, 35, 57
571058 KIT, output adapter, NPT
3A0522
571070 KIT, output, adapter, BSPP
571060 KIT, fill, zerk, leakproof NA
571179
KIT, repair, reservoir oil, 2 liter
models, includes Ref 13, 36, 40b
3A0534571182
KIT, repair, reservoir, oil 4 liter
models, includes Ref 13, 36, 40b
571183
KIT, repair, reservoir, grease, 4 liter
models, includes Ref 13, 36, 40b
127685 RING, fixing, for CPC connector NA
16G022 FILLER CAP NA
Kit No. Description
Manual
Number
571155 KIT, reservoir conversion, 4 Liter
3A1260
571156 KIT, reservoir conversion, 8 Liter
571157 KIT, reservoir conversion, 12 Liter
571158 KIT, reservoir conversion, 16 Liter
571299 KIT, reservoir conversion, 4L Top
Fill
3A8295
571286 KIT, reservoir conversion, 4 Liter
3A5051
571287 KIT, reservoir conversion, 8 Liter
571288 KIT, reservoir conversion, 12 Liter
571289
KIT, reservoir conversion, 16 Liter
Part Description Qty
571039 FUSE, 7.5 A for 12 volt DC
1
571040 FUSE, 4A for 24 volt DC
1
