Selecting the Right Tip
14 3A1177B
Tip Number
The last three digits of tip number (example 262413)
contain information about hole size and fan width when
gun is held 30.5 cm (12 in.) from surface being sprayed.
Reversible Tip Selection Table
Example: For an 203-254 mm (8-10 in.) fan width and a
0.33 mm (0.013 in.) hole size, order part no. 262413.
•See manual 312830 for SG3 gun operating instructions and spray techniques.
Tip Part Number
Fan Width
305 mm (12 in.) from surface
Hole Size
262313 152-203 mm (6-8 in.) 0.33 mm (0.013 in.)
262413 203-254 mm (8-10 in.) 0.33 mm (0.013 in.)
262415 203-254 mm (8-10 in.) 0.38 mm (0.015 in.)
262515 254-305 mm (10-12 in.) 0.38 mm (0.015 in.)
262417 203-254 mm (8-10 in.) 0.43 mm (0.017 in.)
262517 254-305 mm (10-12 in.) 0.43 mm (0.017 in.)
262519 254-305 mm (10-12 in.) 0.48 mm (0.019 in.)
262619 305-356 mm (12-14 in.) 0.48 mm (0.019 in.)
