Technical Data
3A1177B 23
Technical Data
*Measured while spraying water-based paint - specific gravity 1.36 through a 517 tip at 207 bar, 21 MPA (3000 psi)
per ISO 9614-2. Actual sound levels may vary with length of extension used.
A30 A45
Maximum fluid working pressure - sprayer 207 bar, 21 MPa (3000 psi)
Sprayer inlet size 3/4 in. internal thread (standard garden hose USA)
Sprayer outlet size 1/4 npsm external thread
Electric motor (open frame universal motor) 1/2 hp 4.5 Amp 5/8 hp 4.5 Amp
Sprayer weight only 6.1 kg (13.3 lb) 10.6 kg (23.3 lb)
Dimensions:
Length 36.0 cm (14.5 in.) 49.5 cm (19.5 in.)
Width 31.5 cm (12.4 in.) 38.9 cm (15.3 in.)
Height 45.5 cm (17.9 in.) 94.0 cm (37.0 in.)
Wetted parts sprayer Stainless steel, brass, ultra-high molecular weight polyethylene
(UHMWPE) leather carbide, nylon, aluminum, PVC, polypropylene,
fluroelastomer
Inlet Screen on Suction Tube 450 micron (35 mesh)
Maximum material temperature 50° C (120° F)
Electrical power requirement 220 - 240V AC 50/60 Hz, 1 phase, 10A
Sound data* SG3 spray gun:
Sound pressure level 78 dB(A) to 85 dB(A)
Sound power level 87 dB(A) to 89 dB(A)
Storage temperature range -30° to 160° F (-35° to 71° C)
Operating temperature range 40° to 115° (4° to 46° C)
