Spraying Techniques
3A1177B 15
Spraying Techniques
Motor runs only when gun is triggered. Sprayer is
designed to stop pumping when gun trigger is released.
Pressure Adjustment
1. Align arrow on sprayer with spray symbol on pres-
sure control knob.
2. Turning knob right (clockwise) increases pressure at
gun.
3. Turning knob left (counterclockwise) decreases
pressure at gun.
Getting Started
Hold gun 30 cm (12 in.) from surface and aim straight at
surface. Tilting gun to direct spray angle causes an
uneven finish.
4. Flex wrist to keep gun pointed straight. Fanning gun
to direct spray angle causes uneven finish.
Triggering Gun
Pull trigger after starting stroke, release trigger before
end of stroke. Gun must be moving when trigger is
pulled and released.
Aiming Gun
Aim tip of gun at edge of previous stroke to overlap each
stroke by half.
ti2031a
ti2032a
ti2020a
ti2035a
ti2036a
ti2037a
ti2038a
