Parts
312394C 37
† Not shown. See Integrated Heat manual referenced at beginning of this manual.
▲
Replacement Danger and Warning labels, tags, and cards are available at no cost.
Ref Part Description Qty
301 LC0235 TANK, 7.5 L stainless steel, high level
(assembly LC0237 only)
1
LC0236 TANK, 7.5 L stainless steel, high level, shut-off
(assembly LC0238 only)
1
LC0012 TANK, 7.5 L stainless steel
(assembly LC0254 only)
1
255284 TANK, 7.5 L stainless steel, shut-off
(assembly LC0255 only)
1
302 LC0861 BLANKET, heat, 7.5L tank, 220V 1
303 256558 SWITCH, assy, thermal, 125C, 3P, M8 1
304 LC0056 BLANKET, insulation 1
304a
121208
LABEL, hot surface
305 256611 SENSOR, assy, 1.5 in. rtd, 4-pin M8 1
306 121615 HARNESS, splitter, M8, 4-pin, female/male, 3 m 1
307 121478 FITTING, compression, 3/16 x 1/4 npt 1
308 256612 SENSOR, assy, 4.25 in. rtd, 4-pin M8 1
309 121682 CABLE, M8, 3-pin, male / female, 3 meter,
molded
1
310
†
121633 CIRCUIT, breaker, 2-pole, 4A, C type 1
