On-Board Stainless Steel Feed Systems
36 of 71
Figure 44: ASSY,7.5L,HT 220V ( P/N LC0016 TANK)
1 LC0012 TANK ASSY,7.5L SST
2 LC0859 BLANKET ASSY, HT, 7.5L
3 LC0860 HARNESS,THERMOCOUPLE.J TYPE
4 LC0056 INSULATION BLANKET ASSY,7.5L TANK
Figure 45: TANK ASSY,7L,SHUTOFF,HT 220V (P/N LC0017)
1 255284 TANK ASSY,7.5L SST WITH BALL VALV
2 LC0859 BLANKET ASSY, HT, 7.5L
3 LC0056 INSULATION BLANKET ASSY,7.5L TANK
4 LC0860 HARNESS,THERMOCOUPLE.J TYPE
312394B
