On-Board Stainless Steel Feed Systems
Figure 46: LID ASSY DUST COVER (P/N LC0018)
1 15M956 LID,TANK,TFM,DUST COVER
2 96/0127/98 SCREW,SHC,1/4-20X0.37,SS@@@
3 96/0148/11 KNOB,1/4-20,F,PLASTIC
4 96/0311/98 WASHER,LOCK,1/4,HC,SS
Figure 47: LID ASSEMBLY, 3-7.5L CLAMP DOWN, PLAIN (P/N LC0019)
1 94/0370/98 PLUG,SKT HD,1/4NPT,SS 6 96/0176-1/98 NUT,LOCK,8-32,NYLOCK,SS@@@
2 94/0736/96 VALVE,DRAIN COCK,1/4NPT,M,BRS 7 96/0282/98 SCREW,BHCS,8-32X0.38,SS@@@
3 94/0752-D/97 VALVE,RELIEF,9/16-32,5PSI 8 96/0820/98 CLAMP,OVER THE CENTER,SS
4 95/0518/00 O-RING,VIT,JJF,> 9 15M320 LID,7L,2 1/4" NPT AND 1 9/16-32 PORTS
5 95/0524/01 GASKET,LID,TFM,NIT 10 15M392 TANK MODIFICATION
312394B 37 of 71
