Off-Board Stainless Steel Feed Systems
Figure 81: 30L LID ASSY WITH AGITATOR (P/N LC0044)*
1 94/0372/98 PLUG,SKT HD,3/4NPT,SS 4 VALVE,RELIEF,1/4NPT,M,40PSI,SIL 15R145
2 94/0568/98 BUSHING,1/2NPTX1/4NPT,3K,SS 5 255386 MOTOR ASSY,LID,AGIT
3 94/0736/96 VALVE,DRAIN COCK,1/4NPT,M,BRS 6 15M621* LID,AG,7.5 AND 15 GALLON TANKS,SST
* PART CANNOT BE ORDERED AS A SPARE. REPLACEMENT TANK ASSEMBLY 255389 MUST BE ORDERED
Figure 82: 30L LID ASSY WITH AGITATOR AND VACUUM DEGAS (P/N LC0045)*
1 82/0220-1 /11 GAUGE,PRESS/VAC,30"HG-30PSI,2-1/2",LQUD 5 255384 MANIFOLD,VACUUM TREE,3/4" NPT
2 94/0372/98 PLUG,SKT HD,3/4NPT,SS 6 255386 MOTOR ASSY,LID,AGIT
3 94/0568/98 BUSHING,1/2NPTX1/4NPT,3K,SS 7 15M621* LID,AG,7.5 AND 15 GALLON TANKS,SST
4 15R145 VALVE,RELIEF,1/4NPT,M,40PSI,SIL
* PART CANNOT BE ORDERED AS A SPARE. REPLACEMENT TANK ASSEMBLY 255389 MUST BE ORDERED
312394B 62 of 71
