Off-Board Stainless Steel Feed Systems
Figure 87: 60L LID ASSY WITH AGITATOR AND VACUUM DEGAS (P/N LC0050)*
1 82/0220-1/11 GAUGE,PRESS/VAC,30"HG-30PSI,2-1/2",LQUD 6 255384 MANIFOLD,VACUUM TREE,3/4" NPT
2 94/0373/98 PLUG,SKT HD,1"NPT,SS 7 255386 MOTOR ASSY,LID,AGIT
AGITATOR ASSY,15 GAL
LID MOD,15 GAL,SST,AGITATOR
* PART CANNOT BE ORDERED AS A SPARE. REPLACEMENT TANK ASSEMBLY 255390 MUST BE ORDERED
3 94/0744/98 BUSHING,3/8NPTX1/4NPT,SS> 8 255388
4 15R145 VALVE,RELIEF,1/4NPT,M,40PSI,SIL 9 15M836*
5 96/0818/99 RING,RET,EXT,0.750,MS
Figure 88: 30L LID ASSY WITH AGITATOR, VACUUM DEGAS, & FILL PORT (P/N LC0051)*
1 96/0818/99 RING,RET,EXT,0.750,MS 3 LC0046 LID ASSY,AGIT,VAC DEGAS,FILL PORT
2 255387 AGITATOR ASSY,5 GAL
* PART CANNOT BE ORDERED AS A SPARE. REPLACEMENT TANK ASSEMBLY 255389 MUST BE ORDERED
312394B 65 of 71
