Graco ProControl 1KE Plus Instructions-Parts List

Installation
Grounding Grounding
Grounding
Theequipmentmustbegroundedtoreducethe
riskofstaticsparkingandelectricshock.Electric
orstaticsparkingcancausefumestoigniteor
explode.Impropergroundingcancauseelectric
shock.Groundingprovidesanescapewireforthe
electriccurrent.
1.Power Power
Power
Supply Supply
Supply
Modules Modules
Modules
16M167 16M167
16M167
and and
and
26C724: 26C724:
26C724:
RefertotheISPowerSupplyModulesmanual.
2.ProControl ProControl
ProControl
1KE 1KE
1KE
Plus Plus
Plus
ADCM: ADCM:
ADCM:
Connectaground
wiretothescrewonthetopofthebracket.
Connecttheotherendtoatrueearthground.In
anISsystem,theProControl1KEPlusADCM
isalsogroundedbyconnectiontothegrounded
powersupply.
3.External External
External
Mounted Mounted
Mounted
Flow Flow
Flow
Meter: Meter:
Meter:
Followthe
instructionsinmanual308778(G3000,S3000,
G250)ormanual313599(Coriolis)toground
the󰘱owmeterandcheckitselectricalgrounding
continuity.
4.Fluid Fluid
Fluid
and and
and
Air Air
Air
Control Control
Control
Panel: Panel:
Panel:
Connectaground
wiretothescrewonthe1KEPlus󰘱uidpanel.
Connecttheotherendtoatrueearthground.
5.Fluid Fluid
Fluid
Supply: Supply:
Supply:
Groundthe󰘱uidsupplysystem.
Cable Cable
Cable
Connections Connections
Connections
to to
to
the the
the
Advanced Advanced
Advanced
Display Display
Display
Control Control
Control
Module Module
Module
(ADCM) (ADCM)
(ADCM)
Port Port
Port
Description Description
Description
Connection Connection
Connection
1
FiberOpticReceiverRedLeadfromTXonFiberOpticConverter(PN16K465)orfromPort6
onanotherProControl1KEPlus(orInformer)
2
FiberOpticTransmitterBlackLeadtoRXonFiberOpticConverter(PN16K465)ortoPort5on
anotherProControl1KEPlus(orInformer)
3Power
FromPowerSupply
4
DigitalInput/OutputTo/FromMeterandLightTower(Accessory)
5
FiberOpticReceiverBlackLeadfromPort2onanotherProControl1KEPlus(orInformer)
6
FiberOpticTransmitterRedLeadtoPort1onanotherProControl1KEPlus(orInformer)
7
AnalogInput
To/FromPressureTransducerCable
8
FlowControlTo/FromFlowControlCable
9
AtomizingAirControlTo/FromAtomizingAirControlCable
10AnalogInput
FromAirFlowSwitch(AFS)orGunTrigger
3A6948A23
