Graco ProControl 1KE Plus Instructions-Parts List

ProControl1KEPlusModels
Power Power
Power
Supply Supply
Supply
Selection Selection
Selection
Guide Guide
Guide
TopreventFireandExplosion,whenusingaPro
Control1KEPlussysteminahazardouslocation,
useapowersupplywithanISbarrier.
Powersupplymodulesareorderedseparatelyand
dependonwhetheryourProControl1KEPlussystem
isbeingusedinanon-hazardousorhazardous
location.Additionalconsiderationsforeachlocation
arediscussedbelow.
Note
Powersupplymodulescomewithpower
cablestoconnecttoport3oftheProControl
1KEPlusADCMuserinterface.
Non Non
Non
- -
-
Hazardous Hazardous
Hazardous
Locations Locations
Locations
Orderpowersupply16V680(AC/DCConverter)and
chooseapowercordbelow.
Note
The16V680AC/DCConverterhasan
IEC-320-C13femaleinputpowerconnection
anda68in.(1.7m)outputcordtoconnect
toport3oftheProControl1KEPlusADCM
userinterface.
•245202–120in.(3m)NorthAmerican120VAC
powercord.
•116281–72in.(1.8m)extension(MalexFemale)
IEC-320cord.
•242001–8in.(0.2m)IEC-320European-style
powercord.
•242005–8in.(0.2m)IEC-320ANZ-stylepower
cord.
Hazardous Hazardous
Hazardous
Locations Locations
Locations
Todeterminethecorrectpowersupplymodule,
answerthesequestions:
Yes Yes
Yes
No No
No
WillyoubeusingProControl1KE
Plusmodels25B296–25B299for
󰘱uidandatomizingaircontrol?
Wouldyoupotentiallywantto
upgradeaProControl1KEPlus
modelinthefutureforusewith󰘱uid
andatomizingaircontrol?
Doyouneedtopowermorethan
oneProControl1KEPlusunit,or
wanttheabilitytopowerupto
threeunitsfromonepowersupply
moduleinthefuture?
Willyourapplicationeverrequire
greaterthan50psi(3.4bar)of
󰘱uidpressureattheoutletofthe
ProControl1KEPlusforunitswith
thestandardGraco24C3751:1
LowFlowRegulator;
or,
forunitsusinganalternate
air-operated󰘱uidregulator,willyour
applicationeverrequiregreater
than50psi(3.4bar)ofairpilot
pressuretothe󰘱uidregulator?
Ifyouanswered“Yes”toanyofthesequestions,
orderthe26C724ISG-BarrierPowerSupplyModule.
Note
UptothreetotalProControl1KEPlusmodels
ofanycon󰘰gurationcanbepoweredby
asingleG-Barrier.Ifyouareaddinga
ProControl1KEPlusmodeltoanexisting
26C724G-BarrierPowerSupplyModule,
orderapowercablekit19Y499(50ft(16m))
or19Y502(100ft(32m)).
Ifyouanswered“No”toallofthesequestions,you
mayconsiderorderingthe16M167SingleISBarrier
PowerSupplyModule.
Note
The16M167SingleISBarrierPowerSupply
Modulehaspowerlimitations.Itcannotbe
usedonProControl1KEPlusmodelsthat
requiregreaterthan50psi(3.4bar)of󰘱uid
pressure(50psi(4.4bar)ofpilotairpressure
foralternateair-operated󰘱uidregulatoruse),
oronunitsthatcontrol󰘱uidandatomizingair.
3A6948A
7
