Graco Reactor H-40 Series Repair And Parts

Parts
312063Z 55
H-40 and H-XP3 Models
Ref. Description
253400
H-40
12.0 kW
(230V,
1 phase)
253401
H-40
15.3 kW
(230V,
3 phase)
253402
H-40
15.3 kW
(400V,
3 phase)
253403
H-XP3
12.0 kW
(230V, 1
phase)
253404
H-XP3
20.0 kW
(230V,
3 phase)
253405
H-XP3
20.0 kW
(400V,
3 phase)
253407
H-40
20.4 kW
(230V,
3 phase)
253408
H-40
20.4 kW
(400V,
3 phase)
Qty.
2 HEATER; pages 59-61 247834 247813 247813 247834 247833 247833 247833 247833 2
3 MOTOR; page 50 247810 247785 247785 247810 247785 247785 247785 247785 1
6 BOARD, motor
control; page 48
247835 247835 247835 247835 247835 247835 247835 247835 1
8 TRANSFORMER; page
48
247786 247786 247786 247786 247786 247786 247786 247786 1
11 PUMP,
proportioning;
page 57
Model 120 Model 120 Model 120 Model 80 Model 80 Model 80 Model 120 Model
120
1
14 TUBE, inlet,
component A;
page 49
247776 247776 247776 247776 247776 247776 247776 247776 1
15 TUBE, outlet,
component A;
page 49
247775 247775 247775 247775 247775 247775 247775 247775 1
16 TUBE, inlet,
component B;
page 49
247773 247773 247773 247773 247773 247773 247773 247773 1
17 TUBE, outlet,
component B;
page 49
247774 247774 247774 247774 247774 247774 247774 247774 1
26 MODULE, breaker;
page 66
C D E C D E D E 1
35 COVER, heater wire 247502 247502 247502 247502 247502 247502 247502 247502 2
36 BRACKET, heater;
page 46
247843 247843 247843 247843 247843 247843 247843 247843 2
52 COVER, heater 247846 247846 247846 247846 247846 247846 247846 247846 2
66 CONNECTOR, 2-pin,
motor power
120871 120871 1
68 SWITCH, added pole;
400V only
123968 123968 123968 1
100 LABEL 247780 247780 247780 247781 247781 247781 247780 247780 1
103 CONDUIT, assy, motor
power
247814 247790 247790 247814 247790 247790 247790 247790 1
