Graco Reactor H-40 Series Repair And Parts

Parts
56 312063Z
H-50 Models
Ref. Description
253725
H-50
12.0 kW
(230V, 1 phase)
253726
H-50
15.3 kW
(230V, 3 phase)
253727
H-50
15.3 kW
(400V, 3 phase)
256505
H-50
20.4 kW
(230V, 3 phase)
256506
H-50
20.4 kW
(400V, 3 phase)
Qty.
2 HEATER; pages
59-61
247834 247813 247813 247833 247833 2
3 MOTOR; page 50 247810 247785 247785 247785 247785 1
6 BOARD, motor
control; page 48
247835 247835 247835 247835 247835 1
8 TRANSFORMER;
page 48
247786 247786 247786 247786 247786 1
11 PUMP,
proportioning;
page 57
Model 140 Model 140 Model 140 Model 140 Model 140 1
14 TUBE, inlet,
component A;
page 49
247776 247776 247776 247776 247776 1
15 TUBE, outlet,
component A;
page 49
247775 247775 247775 247775 247775 1
16 TUBE, inlet,
component B;
page 49
247773 247773 247773 247773 247773 1
17 TUBE, outlet,
component B;
page 49
247774 247774 247774 247774 247774 1
26 MODULE, breaker;
page 66
C D E D E 1
35 COVER, heater wire 247502 247502 247502 247502 247502 2
36 BRACKET, heater;
page 46
247843 247843 247843 247843 247843 2
52 COVER, heater 247846 247846 247846 247846 247846 2
66 CONNECTOR, 2-pin,
motor power
120871 1
68 SWITCH, added pole;
400V only
123968 123968 1
100 LABEL 256509 256509 256509 256509 256509 1
103 CONDUIT, assy,
motor power
247814 247790 247790 247790 247790 1
