Component Identification
16 3A2776K
User Interface Display
Main Display Screen Components
NOTE: For detailed screens information, see Appendix A - User Interface Display beginning on page 67.
The following figure calls out the navigational, status, and general informational components of each display screen.
The system ratio mode shows if the mix ratio target is by volume or weight . If the weight is crossed out,
the system must be calibrated before running. See Pump and Metering Test and Calibration for Ratio by Weight
Mode on page 48.
FIG. 8: Main Display Screen Components (shown with all display features enabled)
Current Date and Time
Go back one screen
Navigational Bar
Function Display
Remaining Potlife Time System Ratio Mode
(Volume/Weight)
To Next Page
