Accessories
24 311882U
Accessories
Grounding Clamp
Bleed-Type Master Air Valve
300 psi (2.1 MPa, 21 bar) Maximum Working
Pressure
Air Line Filter
250 psi (1.7 MPa, 17.5 bar) Maximum Working
Pressure
Air Line Lubricator
250 psi (1.7 MPa, 17.5 bar) Maximum Working
Pressure
Air Line Filter and Regulator
180 psi (1.3 MPa, 13 bar) Maximum Working
Pressure
Air Regulator and Gauge
300 psi (2.1 MPa, 21 bar) Maximum Working
Pressure
Part Description Qty.
103538 CLAMP, ground
1
Part Description Qty.
107142 VALVE, ball, vented; 1/2 npt(m) inlet x
1/2 npt(f) outlet
1
Part Description Qty.
106149 FILTER, air line; 1/2 npt(f) inlet and
outlet
1
Part Description Qty.
214848 LUBRICATOR, air line; 8 oz (0.24 liter)
bowl capacity; 1/2 npt(f) inlet and outlet
1
Part Description Qty.
202660 FILTER, air; includes gauge and two 1/4
npt(m) outlet valves, 50 micron filter
element with 100 mesh inlet strainer; 1/2
npt(f) inlet; flow rate is over 50 scfm (1.4
m
3
/min).
1
