Graco TrueCoat 360 VSP User Manual

Know Your Controls
10 3A9014A
Know Your Controls
Prime Knob
The Prime Knob directs fluid to either the cup
or the Spray Tip. When priming, it is used to
purge air from the pump. Your sprayer will
not spray with air in the pump.
Turn Prime Knob down to PRIME position to
relieve system pressure.
Turn Prime Knob forward to SPRAY position
to spray fluid.
VacuValve
The VacuValve is used to evacuate air out of
the FlexLiner. This is necessary for the
sprayer to prime.
Spray Tip
The Spray Tip is the key to airless spray
technology. High pressure paint pumped
through the very small hole in the Spray Tip
comes out as a spray.
The Spray Tip has the ability to be reversed
and quickly clear clogs.
Trigger
The Trigger controls the operation of the
sprayer.
Speed Control
The Speed Control* allows you to slow down
or speed up when spraying.
*Available on select models only

Graco TrueCoat 360 VSP Specifications

General

Power Source	Electric
Adjustable Speed	Yes
Voltage	120V
Spray Pattern	Adjustable
Nozzle Sizes Included	1
Adjustable Pressure	Yes
Type	Airless
Tip Size	0.015 inches
Orifice Size	0.015 inches
Material	Plastic, Metal
Spray Tip Sizes Included	0.015 inch
