Graco TrueCoat 360 VSP User Manual

Startup
14 3A9014A
Startup
1. Install the cup onto the sprayer as
follows:
a. Verify Pump Filter is installed and
clean.
b. Align VacuValve (on Cup Lid) with
Prime Knob (on sprayer).
c. Push cup assembly onto the
sprayer, twist to lock.
2. Prime the pump as follows:
a. Verify Prime Knob is pointed down
to PRIME position.
b. Plug sprayer into a grounded
power source.
c. Open the VacuValve cap and
gently squeeze the FlexLiner until
no more air bubbles appear in the
VacuValve.
NOTE: Tilt the sprayer such that the
VacuValve is the highest point so that all air
in the FlexLiner can be fully evacuated.

Graco TrueCoat 360 VSP Specifications

General

Power Source	Electric
Adjustable Speed	Yes
Voltage	120V
Spray Pattern	Adjustable
Nozzle Sizes Included	1
Adjustable Pressure	Yes
Type	Airless
Tip Size	0.015 inches
Orifice Size	0.015 inches
Material	Plastic, Metal
Spray Tip Sizes Included	0.015 inch
