Replacement Parts
3A9014A 31
Parts List- Single Speed, Dual Speed, Dual Speed Premium
Ref. Sprayer Name
Order
Part No.
Description
1 All 18F756 Complete pump assembly includes 2, 3, 5, 6, 7, 8
2 All 16Y425 O-ring
3
All
18A886 Filter, pump, paint
18F209 Filter, pump, stain
5 All 117059 O-ring
6 All 17A402 Prime Pump/Spray valve includes qty. 1 of ref. 5
7 All 17A221 Kit, Prime Pump/Spray knob includes qty. 1 of ref. 8
8 All 119236 Screw, T-15 (torque 8-10 in-lb / 0.9-1.1 N•m)
9 All
18F520 Kit tips, paint includes 3 (CAN models order CAN520)
18F519 Kit tips, stain includes 3 (CAN models order CAN519)
10 All 16X880 Reciprocator assembly
12 Single Speed 17A224 Control, electronic, single speed, 120V includes motor, air
duct, power cord and switch
Dual Speed 17B653 Control, electronic, dual speed, 120V includes motor, air
duct, power cord and switch
13a Dual Speed 16X868 Switch, dual speed control
13b Single Speed 16X869 Plug, single speed
14 All 16W846 Support, 32 oz. cup
15 All 17A226 Kit, 32oz., FlexLiner (3-pack)
16 All 17R821
Kit, cup assembly includes 14, qty. 1 of ref. 15, 16a, 17, qty.
1 of ref. 18
16a All 17M879 Plug, cup lid, not shipped with sprayer (not shown)
17 All 18F759 Lid, cup includes qty. 1 of ref. 18
18 All 17P712 VacuValve cap, 3-pack
19 All 17A227 Kit, enclosure includes qty. 13 of ref. 8
20 All 16Y680 Label, USA
22 All 16Y678 Label, control
23 ▲ All 16Y636 Label, warning and model number, side (not shown)
24
Single Speed 18C037 Label, brand, TrueCoat 360
Dual Speed Premium 18C038 Label, brand, TrueCoat 360 DSP
Dual Speed 18C040 Label, brand, TrueCoat 360 DS
25 ▲ All models 17A198 Label, warning, cord (not shown)
26 Dual Speed Premium 18F449 Case, storage
30 All 18B057 Kit, funnel, strainer includes qty. 1 of ref. 2
31 All 25T467 Lubricant, seal lube
32 All 17K515 Label, A+ Service (not shown)
33 All 18B058 Spout, pour
- - ▲ All 179960 Card, medical alert (not shown)
- - - All 243104 Pump Armor, 32 oz. (not shown)
- - - All 18C045 Tag, hang, tip (not shown) (CAN models order 18F613)
- - - All 17F518 Kit, 42 oz. cup (not shown)
- - - All 17F005 Kit, 42 oz. FlexLiner (3-pack) (not shown)
▲ Replacement safety labels, tags, and cards are available at no cost.

Graco TrueCoat 360 VSP Specifications

General

Power Source	Electric
Adjustable Speed	Yes
Voltage	120V
Spray Pattern	Adjustable
Nozzle Sizes Included	1
Adjustable Pressure	Yes
Type	Airless
Tip Size	0.015 inches
Orifice Size	0.015 inches
Material	Plastic, Metal
Spray Tip Sizes Included	0.015 inch
