Grady-White 360 express - Volt DC Trim Tab Diagram

360 EXPRESS
8–50
12 Volt DC Trim Tab Diagram
LINE
NO.
14 GA BLK
SEE DWG
360-DC-5
LINE 7
1. 3.
14 GA ORG
BOW DOWN BOW UP
14 GA ORG
STBD
TRIM TAB
SW.
PORT
TRIM TAB
SW.
BENNETT
TRIM TAB
HYDRAULIC
PUMP
16 GA Y16 GA Y
16 GA BLU 16 GA GRN 16 GA R 16 GA BLK 16 GA BLK
16 GA R 16 GA GRN 16 GA BLU
MOTOR REVERSE MOTOR FORWARD PORT SOLENOID VALVE STBD SOLENOID VALVE DC NEG.
TRIM
POSITION
INDICATOR
(TPI)
22 GA BLK
SEE DWG
360-DC-11
LINE 9
(-)
22 GA ORG
(+)
GRN
GRN
SHEILD
RED
RED
22 GA GRN
22 GA GRN
SHIELD
22 GA R
22 GA R
STBD ACTUATOR
BENNET CABLE
GRN
NOTES:
1) INDICATES MULTI-CONDUCTOR CABLE
BENNET CABLE
RED
PORT ACTUATOR
2.
16 GA R
16 GA Y
16 GA GRN
(+)
22 GA ORG
(-)
SEE DWG
360-DC-11
LINE 8
22 GA BLK
AUTO TAB
RETRACTOR
(ATR)
14 GA ORG
14 GA ORG
22 GA ORG
22 GA ORG
1.5A 1.5A
360-DC-9
