Grady-White 360 express - Air Condition & Cockpit Coolers One-Line Diagram

360 EXPRESS
8–54
Air Condition & Cockpit Coolers One-Line Diagram
GN
FROM DWG 360-AC-1
AIR/COOLER PUMP CB
W BLK
3C 14 GA
BLK
W
GN
PR3X-2
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
NOTES:
1) INDICATES MULTI-CONDUCTOR CABLE
RR3X-2
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
GN
W
BLK
3C 14 GA
BLK W
FROM DWG 360-AC-1
COCKPIT COOLERS CB
GN
2C 14 GA
RAW WATER
PUMP
3C 14 GA
GN
FROM DWG 360-AC-1
AIR COND CB
W BLK
3C 10 GA
BLK
W
GN
AIR COND
UNIT
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
2C 14 GA
AIR COND
CONTROL
PANEL
DATA CABLE
CONDENSING
UNIT
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
3C 14 GA
TEMP
CONTROLLER
PORT COOLER
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
TEMP
CONTROLLER
AFT FISHBOX
(SEE
COMPONENT
OWNER'S
MANUAL FOR
INTERNAL
WIRING)
3C 14 GA
3C 14 GA
2C 14 GA
2C 14 GA
PORT SOLENOID
AFT SOLENOID
LINE
NO.
1.
2.
3.
4.
5.
6.
7.
8.
360-Air Cond-1
