Access Plate And Hull Rigging Tube Locations
6"
6" Access Plate
A
B
D
E
F
G
3" X 120"
3" X 104"
3" X 40"
3" X 31"
3" X 26"
3" X 25"
2" X 134" 1 ea
3 ea
6 ea
4 ea
2 ea
2 ea
2 ea
QtyDescription#
1 ea2" X 108"
H
I
1" X 145" 1 ea
3" X 89"C4 ea
J
A (4 pcs.)
B (2 pcs.)
D (2 pcs.)
E (2 pcs.)
F
J
A (2 pcs.)
F
G (2 pcs.)
H
E
I
6"
6" Access Plate
6" 6" 6"
6"
6"
6"
6"
4"
4"
6" Access Plate
4" Access Plate
6" Access Plate
(vertical beneath helm seat)
6" Access Plate
6" Access Plate
(vertical beneath head sink)
6" Access Plate
4" Access Plate
(vertical on TV cabinet)
6"
6" Access Plate
(vertical inside trash can compartment)
