360 EXPRESS
8–47
12 Volt DC Wiper/Washer System Diagram
LINE
NO.
FROM DWG
360-DC-5 LINE 8
CENTER
WIPER
MOTOR
14 GA ORG
14 GA ORG/PUR
14 GA BLK
14 GA BLK
14 GA ORG/GRN
14 GA ORG
PORT
WIPER
MOTOR
FROM DWG
360-DC-5 LINE 8
FROM DWG
360-DC-5 LINE 8
STBD
WIPER
MOTOR
14 GA ORG
14 GA ORG/BLK
14 GA BLK
FROM DWG
360-DC-5 LINE 8
14 GA ORG/PNK
14 GA ORG/PNK
14 GA ORG/PNK
14 GA ORG/PNK
14 GA BLK
2.
3.
4.
5.
14 GA BLK
WASHER
SOLENOID
VALVES
1.
16 GA BLK
P3-4
P3-2
P3-7
P3-8
P3-1
P3-3
P3-6
P10 - 5
16 GA ORG
16 GA ORG
16 GA ORG
14 GA BLK
16 GA ORG
16 GA ORG
16 GA ORG
16 GA ORG
360-DC-6
