Grady-White 360 express - Accessory Wiring Color - Fuse;Breaker Sizes

M AINTENANCE AND SERVICE
6–9
ACCESSORY WIRING COLOR – FUSE/BREAKER SIZES
Accessory Wire Size & Color Amps Fuse/Breaker Location
Lights
Bow Light 14 ga. Gray 10.0 Helm Accessory Panel
Cabin Lights 16 ga. Blue/Green 20.0 AC/DC Panel
Cockpit Lights 16 ga. Blue/Yellow 10.0 Helm Accessory Panel
Hard Top Dome Light 16 ga. Blue/Gray 5.0 Fuse Block
Livewell Light 16 ga. Blue/Red w/ Pump Cockpit Accessory Panel
Mast Light 14 ga. Gray/Red
w/ Bow
Light
Helm Accessory Panel
Panel Lights 16 ga Dark Blue
w/ Nav
Lights
Helm Accessory Panel
Spreader Lights
14 ga Dark Blue/
White
10.0 Cockpit Accessory Panel
Pumps
Bilge Pump (Aft):
Attwood 1700 16 ga. Brown 10.0 Helm Accessory Panel
Auto Float Switch (Aft) 16 ga. Brown/White 10.0 Battery Select Box
Bilge Pump (Forward):
Attwood 1700 16 ga. Brown/Black 10.0 Helm Accessory Panel
Auto Float Switch (Forward) 16 ga. Brown/Red 10.0 Battery Select Box
Head Pump (Discharge) 14 ga. Orange/Gray 10.0 AC/DC Panel
Head Pump (Vaccum) 14 ga. Orange/Red 10.0 AC/DC Panel
Livewell Pump: Sentry 1100 GPH 16 ga. Orange/Brown 6.0 Cockpit Accessory Panel
Power Assist Pump 8 ga. Red 40.0 Bow Thruster Battery Compartment
Shower Sump Pump (Float Switch) 16 ga. Brown/Orange 2.5 AC/DC Panel
Washdown Pump 12 ga. Orange/Brown 15.0 Cockpit Accessory Panel
Water Pressure Pump 12 ga. Orange/Blue 15.0 AC/DC Panel
Anchor Windlass
Main Positive 2 ga. Red 90.0 Battery Select Box
Positive to Switches 14 ga. Red 5.0 In-line @ Solenoid
Down 14 ga. Green/Orange N/A N/A
Up 14 ga. Blue/Orange N/A N/A
Windshield Wiper System
Power to wiper panel / Motor park 14 ga. Orange 15.0 Fuse Block
