M AINTENANCE AND SERVICE
6–10
Port 14 ga. Orange/Green -- Wiper Control Panel
Center 14 ga. Orange/Purple -- Wiper Control Panel
Starboard 14 ga. Orange/Black -- Wiper Control Panel
Washer Solenoid Valves 14 ga. Orange/Pink -- Wiper Control Panel
Miscellaneous
12 Volt Accessory Outlets 10 ga. Red/Orange 15.0 Fuse Block
Accessory Negatives (Branch) (1) Black N/A N/A
Accessory Negatives (Mains) 2/0 or 6 ga. Black N/A N/A
AC/DC Panel Meter Negative 16 ga. Black/Yellow N/A N/A
Blower (Bilge) 10 ga. Brown/Yellow 4.0 AC/DC Panel
Bow Thruster Positive 4/0 Red 400.0 Bow Thruster Battery Compartment
CO Detectors 16 ga. Red/Black 1.0 In-line @ Positive Bus
Constant 12V (Memory) 16 ga. Red/Pink 10.0 Battery Select Box
DC Main Positive 2/0 Red 50.0 Battery Select Box
DC Panel "Main" Positive 6 ga. Red 50.0 AC/DC Panel
Electronics Box Ram 16 ga. White 10.0 Accessory Panel
Fuse Block Positive 6 ga. Red N/A N/A
Fuel Grounds 16 ga. Green N/A N/A
Fuel Tank Sender (Aft) 16 ga. Pink/White N/A N/A
Fuel Tank Sender (Fwd) 16 ga. Pink N/A N/A
Generator Cranking Lead 4 ga. Red 100.0 Main Battery Compartment
Hard Top Negative (Main) 10 ga. Black/Blue N/A N/A
Head Vent 16 ga. Brown/Green 3.0 Fuse Block
Horn 12 ga. Orange/White 10.0 Helm Accessory Panel
Hydraulic Trim Tabs 14 ga. Orange 20.0 Fuse Block
i1000 Positives 8 ga. Red 30.0 Main Battery Compartment
i1000 Negatives 8 ga. Yellow N/A N/A
Center Engine Isolator Lead 6 ga. Red 35.0 Bow Thruster Battery Compartment
Ignition Signal (i6000 & Power Assist) 16 ga. Purple N/A N/A
Seakey Float 16 ga. White/Red N/A N/A
Stereo 16 ga. Red 10.0 AC/DC Panel
TV/DVD 10 ga. Red/Green 10.0 AC/DC Panel
Windshield Vent 16 ga. White/Green 10.0 Helm Accessory Panel
(1) Wire gauge is the same as the gauge of the power wire to the corresponding component.
